Question

1. (50 points) Determine Mn for a beam of cross section shown in figure 1, where f'c = 4 ksi.Assume fy = 60 ksi. Calculate the strain on steel when the concrete strain is 0.003 and compare it with yield strain of steel. Es = 29x10³ ksi

Question image 1Question image 2
