Question
4. (5 pts.) For the system shown below (open-loop polesno finite open-loop zeros):are marked and the system has (a) Sketch the root locus. (b) Find the breakaway point. (c) Find the range of K, where the system is stable
Question image 1Question image 2Question image 3Question image 4Question image 5
