Question

An amplification circuit is designed with a 1 V sinusoidal signal input Vin. What's the output of the circuit V out if the resistors R1=2 khms, R2=8 kohms, R3=5 kohms,R4=10

kohms? A. Inverting output, the amplitude is 10 V, B. Non-inverting output, the amplitude is 10 V, C. Inverting output, the amplitude is 12 V, D. Non-inverting output, the amplitude is 12 V.

Question image 1Question image 2Question image 3Question image 4Question image 5Question image 6
