For the circuit below, Vs is a sinusoidal voltage with Vs(t) = 16 sin (2150 t).If VDO = 0.7 V (constant voltage drop), 1. Analyze the circuit by explaining when

the diode is ON and when the diode is OFF. [10 points] 2. Calculate the peak diode current. [10 points] 3. Sketch Vs(t) and Ip(t). (Horizontal and vertical axis should be detailed with the required values) [20 points] 4. Find PIV of the diode. [10 points]
