/n3-D Results:

3.1

3.2

3-D CED velocity and pressure fields:

Describe the 3-D fields that the CER produces.

Which flow phenomena can you observe in them. Link your observations to the graphs with

Fig no, stating clearly where exactly the figure shows what.

Qualitatively describe the flow behaviour, why is the flow in the simulation doing

what you observe? Is this correct? Or should we see a different behaviour? If you spot any

discrepancy, explain what you think causes it.

Analysis of 3-D pressure drop data:

Quantify the pressure drop predicted by the 3-D simulations.

Compare to at least two of the experimental/heuristic formulae from the literature and the 2-D

results. Use more for higher credit.

Explain any discrepancies.

Summary:

Summarise the methods you have used to arrive at your results.

What are the main results?

Give a concise but complete summary of the main points of your discussion in 2.2 and 3.2.

If you designed a pipe network, which method would you be propose to use to determine the

pressure drop?
