Problem 3 Add the energy grade line (EGL) as a solid line and the hydraulic grade line (HGL) as a dashed line to the figure below. Enter the corresponding numbers

in the table. Assume steady incompressible flow from left to right. At point A, the pressure head Ply = 23 ft and the velocity is V=8 ft/s. The pump adds AH=16 ft.
