Question

Study the fixture and part shown below. On the three views shown, apply datum targets to simulate the fixture shown. The primary and secondary datum targets are clearly shown on

the fixture, but please use datum target point(s) for your tertiary datum. The definition of all datum targets need to be complete, but for location dimensions just use "x.Xxx", since we don't know how big this part is. [20 pts.]

Fig: 1

Fig: 2
