Question

The following steel siphon (L constant elevation difference of 20 m. The distance between reservoir A and siphon summit S is 100 m.500 m, D 200 mm) connects two reservoirs

with a a) Assume f= 0.020 and calculate steady state flow rate between the two reservoirs b) Calculate pressure head at the summit Identify on the figure the region of the system under sub atmospheric pressure
